D-Link DFE-530TX+ Quick Install Guide

3 D-Link DFE-530TX+ Quick Install Guide
Hardware Overview
Hardware Overview
• AcomputerwithanavailablePCIslot
• Windows
®
7,Vista
®
,XPor2000,Linux2.2.xandabove,
 Netware5.x/6.x,orMacOS10.2.x
• 300MHzprocessorandatleast64MBofRAM
• 32MBfreeharddrivespace
• CD-ROMDrive
Link/Activity
Asteadygreenlightindicatesagoodconnectionto
yourethernetdevice.Ablinkinglightindicatesdatais
beingtransmitted(sendingorreceiving).
Speed
When lit, the device speed is
100Mbps.Ifthelightisnotlit,the
devicespeedis10Mbps.

D-Link DFE-530TX+ Specifications

General

Interface	PCI
Data Transfer Rate	10/100 Mbps
Connector	RJ-45
Standards	IEEE 802.3, IEEE 802.3u
LED Indicators	Link/Activity
Device Type	Network adapter
Form Factor	Plug-in card
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet
Full Duplex Support	Yes
Ports	1 x RJ-45
Driver Support	Windows, Linux
