Page #14 background imageLoading...
Page #14 background image
D-Link DGS-105/108 Gigabit Ethernet Switch
7
SECTION 2
Installation
Package Contents
Before You Connect to the Network
Installing the Switch
Power On
Package Contents
Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the following items:
One DGS-105/108 5/8-Port 10/100/1000BASE-T Gigabit Ethernet Switch
One external power adapter
Quide installation guide and warranty guide
If any item is missing or damaged, please contact your local D-Link reseller for replacement.
Before You Connect to the Network
The site where you install the Switch may greatly affect its performance. Please follow these guidelines for setting up the
Switch.
Install the Switch on a sturdy, level surface that can support at least 3 kg (6.6 lbs.) of weight. Do not place heavy
objects on the Switch.
The power outlet should be within 1.82 meters (6 feet) of the Switch.
Visually inspect the power cord and see that it is fully secured to the AC power port.
Make sure that there is adequate space for proper heat dissipation from and adequate ventilation around the Switch.
Leave at least 10 cm (4 inches) of space at the front and rear of the Switch for ventilation.
Install the Switch in a fairly cool and dry place for the acceptable temperature and humidity operating ranges.
Install the Switch in a site free from strong electromagnetic field generators (such as motors), vibration, dust, and
direct exposure to sunlight.
When installing the Switch on a level surface, attach the rubber feet to the bottom of the device. The rubber feet
cushion the Switch, protect the casing from scratches, and prevent it from scratching other surfaces.

Other manuals for D-Link DGS-108

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DGS-108 and is the answer not in the manual?

D-Link DGS-108 Specifications

General IconGeneral
MAC address table8000 entries
Jumbo frames supportYes
Packet buffer memory0.128 MB
Maximum data transfer rate1 Gbit/s
Supported data transfer rates10/100/1000 Mbps
Dimensions (WxDxH)162 x 102 x 28 mm
Connectivity technologyWired
10G support-
Networking standardsIEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology1000BASE-T, 100BASE-TX, 10BASE-T
Switch typeUnmanaged
Switch layerL2
Power connectorDC-in jack
Installed SFP modules quantity0
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity8
CertificationFCC Class B, ICES-003 Class B, CE Class B, C-Tick Class B, VCCI Class B, cUL, CB, RoHS
Product colorBlack
Rack mountingNo
LED indicatorsLink, Power, Y
Housing materialMetal
Input current1 A
Input voltage5 V
Power consumption (typical)4.5 W
Mean time between failures (MTBF)2053751 h
Heat dissipation9.548 BTU/h
Storage temperature (T-T)10 - 70 °C
Operating temperature (T-T)0 - 50 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Weight440 g
