LED Indicators
LED stands for Light-Emitting Diode.
The front panel LEDs provides instant status feedback and simplifies
monitoring and troubleshooting tasks.
LED indicators of the Switch
Power LEDs
On When the Power LED light is on, the Switch is
receiving power.
Off When the Power LED light is off, the power cord
is improperly connected.
CPU LEDs ( Management Indicator)
Blinking When the CPU is working, the System LED is
blinking.
On/Off The CPU is not working.
Ports 1 & 48 Status LEDs
Link/Act
On When the Link/Act LED lights on, the respective
port is successfully connected to an Ethernet
network.
Blinking When the Link/Act LED is blinking, the port is
transmitting or receiving data on the Ethernet
network.
Off No link.
