6
SPEED:
On
(Green)
: When the green light is on, the respective port is
connected to a 1000Mbps Gigabit Ethernet
network.
On
(Amber)
When the Amber light is on, the respective port is
connected to a 100Mbps Fast Ethernet network.
Off : When the respective port is connected to a
10Mbps Ethernet or No link
Option Ports 45~48 Mini-GBIC Status LEDs
Link/Act
On When the Mini GBIC module is installed and
connected to a network, the Link/Act LED lights on.
Blinking When the LED is blinking, the Mini GBIC module is
receiving data on a network.
Off No link.
