mode, and 10Mbps Ethernet or 100Mbps Fast Ethernet modes that
run both in half and full duplex modes; it also has 4 Mini GBIC
Combo Ports. Each port on the DGS-1248T supports Auto-
MDI/MDI-X. Auto-MDI/MDI-X is a feature that eliminates the
need for worrying about using either a standard or crossover
cable—you can use either one—and allows any port to be an
uplink port.
AC Power
The DGS-1248T can be used with an AC power supply of 100~240V
AC, 50~60Hz. The power switch is located at the rear of the unit
adjacent to the AC power connector and the system fan.
The switch’s power supply will adjust to the local power source
automatically and may be turned on without having any or all LAN
segment cables connected.
