MDI/MDIX crossover detection. All these 48 ports can operate in
half- and full- duplex modes for 10/100Mbps, and will be
automatically activated when a compatible terminal is identified.
10/100/1000 BASE-T / Mini GBIC Combo Ports (Option Port
45~48)
The Switch is also equipped with four combo 10/100/1000 Base-T /
Mini GBIC ports, supporting optional 1000BASE-SX/LX Mini
GBIC modules for fiber uplinks.
Note: When a port is set to “Forced Mode”, the Auto MDI/MDIX
will be disabled.
Rear Panel
Figure 5 – Rear panel of the Switch
AC Power Connector:
Plug in the female connector of the provided power cord into this
connector, and the male into a power outlet. Supported input
voltages range from 100-240V AC, and 50-60Hz.
