DIR-816 Wireless AC750 Dual Band Router with 3G/LTE
Support and USB Port
User Manual
Configuring via Web-based Interface
Additional
On page of the Wi-Fi / Additional section, you can define additional parameters for the WLAN of
the router. To configure the 2.4GHz band or 5GHz band, go to the relevant tab.
!
Changing parameters presented on this page may negatively affect your WLAN!
Figure 104. Additional settings of the WLAN.
The following fields are available on the page:
Parameter Description
Bandwidth
The channel bandwidth for 802.11n standard in the 2.4GHz band
(the 2.4GHz tab).
20MHz: 802.11n clients operate at 20MHz channels.
40MHz: 802.11n clients operate at 40MHz channels.
20/40MHz -: 802.11n clients operate at 20MHz or 40MHz channels
(the channel is combined with the previous adjacent channel).
20/40MHz +: 802.11n clients operate at 20MHz or 40MHz channels
(the channel is combined with the next adjacent channel).
The channel bandwidth for 802.11n and 802.11ac standards in 5GHz
band (the 5GHz tab).
20MHz: 802.11n and 802.11ac clients operate at 20MHz channels.
40MHz: 802.11n and 802.11ac clients operate at 40MHz channels.
80MHz: 802.11ac clients operate at 80MHz channels.
TX power The transmit power (in percentage terms) of the router.
Page 129 of 215
