DIR-816 Wireless AC750 Dual Band Router with 3G/LTE
Support and USB Port
User Manual
Configuring via Web-based Interface
Creating PPTP or L2TP WAN Connection
To create a connection of the PPTP or L2TP type, click the ADD button on the Connections
Setup / WAN page in the Connections List section. On the opened page, go to the All
Settings tab. Then select the relevant value from the Connection type drop-down list and
specify the needed values.
Figure 71. The page for creating a new PPTP connection. Selecting a connection type.
Parameter Description
Enable connection
Move the switch to the right to enable the connection.
Move the switch to the left to disable the connection.
Connection name A name for the connection for easier identification.
Page 84 of 215
