D-Link DIR-842 User Manual

DIR-842 AC1200 Wave 2 MU-MIMO Wi-Fi EasyMesh Gigabit
Router
User Manual
Installation and Connection
PC with Wi-Fi Adapter
1. Connect the power cord to the power connector port on the back panel of the router, then
plug the power adapter into an electrical outlet or power strip.
2. Turn on the router by pressing the POWER button on its back panel.
3. Make sure that your Wi-Fi adapter is on. As a rule, modern notebooks with built-in wireless
NICs are equipped with a button or switch that turns on/off the wireless adapter (refer to
your PC documents). If your PC is equipped with a pluggable wireless NIC, install the
software provided with your Wi-Fi adapter.
Then make sure that your Wi-Fi adapter is configured to obtain an IP address automatically (as
DHCP client).
Obtaining IP Address Automatically and Connecting
to'Wireless Network (OS Windows 7)
1. Click the Start button and proceed to the Control Panel window.
2. Select the Network and Sharing Center section. (If the Control Panel has the category
view (the Category value is selected from the View by drop-down list in the top right
corner of the window), choose the View network status and tasks line under the
Network and Internet section.)
Figure 13. The Control Panel window.
Page 28 of 233

D-Link DIR-842 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
High power	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
USB port	No
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2, WPS
Frequency band	2.4 & 5 GHz
Product color	Black
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE, RoHS, FCC, D-Link Green
Package depth	356 mm
Package width	256 mm
Package height	55 mm
Package weight	783 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	2025 mm
Pallet gross weight (air)	333500 g
Quantity per pallet (air)	360 pc(s)
Shipping (inner) case width	377 mm
Shipping (inner) case height	315 mm
Shipping (inner) case length	534 mm
Shipping (inner) case weight	8750 g
Shipping (inner) case net weight	4400 g
Number of cartons per pallet (air)	36 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	133 mm
Width	190 mm
Height	38 mm
Weight	288 g
