D-Link DIR-842 User Manual

DIR-842 AC1200 Wave 2 MU-MIMO Wi-Fi EasyMesh Gigabit
Router
User Manual
Configuring via Web-based Interface
Creating PPPoE IPv6 or PPPoE Dual Stack WAN Connection
On the connection creation page, in the General Settings section, select the relevant value from
the Connection type drop-down list and specify the needed values.
Figure 82. The page for creating a new PPPoE IPv6 connection. The General Settings section.
Parameter Description
General Settings
Interface
A physical or virtual WAN interface to which the new connection
will be assigned.
Connection name
A name for the connection for easier identification.
Enable connection
Move the switch to the right to enable the connection.
Move the switch to the left to disable the connection.
NAT
For the PPPoE Dual Stack type only.
If the switch is moved to the right, the network address translation
function for IPv4 is enabled. Do not disable the function unless your
ISP requires this.
Ping
If the switch is moved to the right, the router responds to ping
requests from the external network through this connection. For
security reasons, it is recommended to disable this function.
RIP
For the PPPoE Dual Stack type only.
Move the switch to the right to allow using RIP for this connection.
RIPng
Move the switch to the right to allow using RIPng for this
connection.
Page 94 of 233

D-Link DIR-842 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
High power	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
USB port	No
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2, WPS
Frequency band	2.4 & 5 GHz
Product color	Black
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE, RoHS, FCC, D-Link Green
Package depth	356 mm
Package width	256 mm
Package height	55 mm
Package weight	783 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	2025 mm
Pallet gross weight (air)	333500 g
Quantity per pallet (air)	360 pc(s)
Shipping (inner) case width	377 mm
Shipping (inner) case height	315 mm
Shipping (inner) case length	534 mm
Shipping (inner) case weight	8750 g
Shipping (inner) case net weight	4400 g
Number of cartons per pallet (air)	36 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	133 mm
Width	190 mm
Height	38 mm
Weight	288 g
