D-Link DIR-842 - Product Appearance; Upper Panel

DIR-842 AC1200 Wave 2 MU-MIMO Wi-Fi EasyMesh Gigabit
Router
User Manual
Overview
Product Appearance
Upper Panel
Figure 1. Upper panel view.
LED Mode Description
Power
Solid green
The router is powered on.
No light
The router is powered off.
Internet
Solid green
The cable is connected to the port.
Blinking green
Data transfer through the WAN port.
No light
The WAN cable is not connected.
Page 13 of 233
