D-Link DIR-865L User Manual

45D-Link DIR-865L User Manual
Section 3 - Conguration
Step 6 - When the site survey screen appears, select the network you
want to connect to (click the radio button under Select) and then click
Connect.
If the network is secure/encrypted, you will need to enter the
passphrase/encryption key.
Please allow a minute to connect.
Step 7 - Once connected, any Ethernet device connected to the
DIR-865L will connect to the wireless network.
Note: Wireless clients cannot connect to the DIR-865L while in bridge mode.
Also, the Internet port on the DIR-865L in Bridge mode will not function.

D-Link DIR-865L Specifications

Device Interfaces

wireless LAN	802.11 a/b/g/n/ac
Gigabit LAN ports	Four 10/100/1000
Gigabit WAN port	10/100/1000
USB port	USB 3.0

Power

input voltage	100 to 240 V AC
input frequency	50/60 Hz
output voltage	12 V DC
output current	2.5 A
USB port power	5 V / 0.9 A

Operating Environment

operating temperature	32°F to 104°F (0°C to 40°C)
humidity	95% maximum (non-condensing)

Weight and Dimensions

length	102.3 mm (4.03 inches)
width	123.3 mm (4.85 inches)
height	217 mm (8.54 inches)
