20D-Link DIR-869 User Manual
Section 2 - Installation
4. Connect the supplied power adapter to the router and a power outlet, press the power button, and wait approximately
one minute until the LED indicator on the front of the device changes from orange to solid white.
5. Connect wired devices to the LAN ports on your DIR-869. Connect wireless devices to the Wi-Fi network printed on
the included Wi-Fi Conguration Card. You can also nd the Wi-Fi network names and passwords printed on the label
attached to the bottom your DIR-869.
Broadband
Connection Device
(e.g. DSL/Cable Modem)
Existing
Router
InternetDIR-869
Access Point Mode
Note: This unit is to be used with power supply model DA-60N12.
Broadband
Connection Device
(e.g. DSL/Cable Modem)
Existing
Router
InternetDIR-869
Access Point Mode
Wired and Wireless Devices
8. No further conguration is necessary, but if you wish to adjust the default settings, proceed to Access Point - Extender
Mode on page 31.
