Statically Assign An IP Address
D-Link DSL-2640B User Manual 118
Statically Assign An IP Address
If you are not using a DHCP capable gateway/router, or you need to assign a static IP address, please follow the steps below:
Step 1
Windows® XP - Click Start > Control Panel > Network Connections.
Windows® 2000 - From the desktop, right-click My Network Places > Properties.
Step 2
Right-click the Local Area Connection that represents your D-Link network adapter and select Properties.
Step 3
Highlight Internet Protocol (TCP/IP) and click Properties.
Step 4
Click on the Use the following IP address and enter an IP
address that is on the same subnet as your network or the
LAN IP address on your router.
Example: If the router’s LAN IP address is 192.168.1.1, make
your IP address 192.168.1.X where X is a number between 2
and 254. Make sure that the number you choose is not in use
on the network. Set Default Gateway the same as the LAN IP
address of your router (192.168.1.1).
Set Primary DNS the same as the LAN IP address of your
router (192.168.1.1). The Secondary DNS is not needed or
you may enter a DNS server from your ISP.
Step 5
Click on the OK twice to save your settings.

Table of Contents

Other manuals for D-Link DSL-2640B

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DSL-2640B and is the answer not in the manual?

D-Link DSL-2640B Specifications

Power IconPower
input voltage100V-240V
input current0.6A
input frequency50 Hz -60 Hz
output voltage12V
output current1A
Data Transfer Rates IconData Transfer Rates
G.dmt full rate downstreamup to 8 Mbps
G.dmt full rate upstreamup to 1 Mbps
G.lite downstreamup to 1.5 Mbps
G.lite upstreamup to 512 Kbps
G.dmt.bis full rate downstreamup to 12 Mbps
G.dmt.bis full rate upstreamup to 1 Mbps
ADSL2+ full rate downstreamup to 24 Mbps
ADSL2+ full rate upstreamup to 1 Mbps
Wireless Transfer Rates IconWireless Transfer Rates
IEEE 802.11b transfer rates11, 5.5, 2, and 1 Mbps
IEEE 802.11g transfer rates6, 9, 12, 18, 24, 36, 48, 54 Mbps
Media Interface IconMedia Interface
ADSL interfaceRJ-11 connector
LAN interfacefour RJ-45 ports
Ethernet connection type10/100BASE-T
