D-Link DSL-2640B User Manual

Web Configuration
D-Link DSL-2640B User Manual 96
MAC Filter
The page allows you to create a list of MAC addresses that are banned or allowed
association with the wireless access point.
MAC Restrict Mode: The function can be turn on/off, Check Disabled to
disable this function. Vice versa, to enable the function. After enabling the function,
you can filter wireless users according to their MAC address, either allowing or denying
access.
Check Allow to make any wireless MAC address in the Wireless Access
Control List can be linked to. And Check Deny to banned any wireless MAC
address in the Wireless Access Control List to be linked to.
Add a MAC Access Control: To add a new MAC address to your wireless
MAC address filters, click Add to show next page. Type in the MAC Address in
the entry field provided. Click Save/Apply to add the MAC address to the list.
The MAC address appears listed in the table below.
Remove a MAC Access Control: Select the Remove checkbox in the right
column of the list for the MAC address to be removed and click Remove.
Choose Allow and click Add, the right page appears.

D-Link DSL-2640B Specifications

Power

input voltage	100V-240V
input current	0.6A
input frequency	50 Hz -60 Hz
output voltage	12V
output current	1A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps

Wireless Transfer Rates

IEEE 802.11b transfer rates	11, 5.5, 2, and 1 Mbps
IEEE 802.11g transfer rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Media Interface

ADSL interface	RJ-11 connector
LAN interface	four RJ-45 ports
Ethernet connection type	10/100BASE-T
