D-Link DSL-2750U User Manual

DSL-2750U Wireless ADSL2+ Router with 3G/LTE/Ethernet WAN Support
and USB Port
User Manual
Configuring via Web-based Interface
Figure 84. The page for creating a new LTE connection. The USB Modem section.
Parameter Description
USB Modem
Mode
The value of the field specifies the type of the network to which the
router connects. Leave the Auto value to let the router connect
automatically to an available type of network, or select a needed
value from the drop-down list.
10
APN
An access point name.
Without authorization
Move the switch to the right if your operator does not require
authorization.
Authentication
protocol
Select a required authentication method from the drop-down list.
Username
A username (login) to connect to the network of the operator.
Password
A password to connect to the network of the operator. Click the
Show icon ( ) to display the entered password.
10 Some LTE USB modems do not support network type selection and work in the Auto mode regardless of the value
selected from the drop-down list.
Page 107 of 210

D-Link DSL-2750U Specifications

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Media Interface

ADSL interface connector type	RJ-11
ADSL interface cable type	24/26 AWG twisted pair telephone line
LAN interface port type	RJ-45
LAN interface standard	10/100BASE-T Ethernet
