DSL-2750U Wireless ADSL2+ Router with 3G/LTE/Ethernet WAN Support
and USB Port
User Manual
Installation and Connection
PC with Wi-Fi Adapter
1. To connect via USB modem: connect your USB modem to the USB port
6
located on the
back panel of the router.
!
In some cases you will need to reboot the router after connection of the USB modem.
2. To connect the router to a DSL line: connect a phone cable between the DSL port of the
router and the ADSL OUT port of the splitter. Connect your phone to the PHONE port of
the splitter. Then connect another phone cable between a phone jack and the ADSL IN port
of the splitter.
3. To connect the router to an Ethernet line: run the Initial Configuration Wizard and select
the router's LAN port that will be used as the WAN port. Then connect the Ethernet cable
between the selected Ethernet port located on the back panel of the router and the Ethernet
line.
4. Connect the power cord to the power connector port on the back panel of the router, then
plug the power adapter into an electrical outlet or power strip.
5. Turn on the router by pressing the ON/OFF button on its back panel.
6. Turn on your PC and wait until your operating system is completely loaded.
7. Turn on your Wi-Fi adapter. As a rule, modern notebooks with built-in wireless NICs are
equipped with a button or switch that turns on/off the wireless adapter (refer to your PC
documents). If your PC is equipped with a pluggable wireless NIC, install the software
provided with your Wi-Fi adapter.
6 It is recommended to use a USB extension cable to connect a USB modem to the router.
