D-Link DSL-2750U User Manual

DSL-2750U Wireless ADSL2+ Router with 3G/LTE/Ethernet WAN Support
and USB Port
User Manual
Configuring via Web-based Interface
Parameter Description
Start All Torrents
Click the button to restart all downloads. If you limited the
maximum number of simultaneous downloads, the Transmission
client starts processing of the specified number of torrent files; after
completing download of the first one, the client proceeds to the next
file in the queue.
Pause Selected
Torrents
Select the torrent file corresponding to the download which should
be stopped and click the button.
Pause All Torrents
Click the button to stop all downloads.
Toggle Inspector
Select a torrent file and click the button to view its data.
Page 151 of 210

D-Link DSL-2750U Specifications

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Media Interface

ADSL interface connector type	RJ-11
ADSL interface cable type	24/26 AWG twisted pair telephone line
LAN interface port type	RJ-45
LAN interface standard	10/100BASE-T Ethernet
