Configuring via Web-based Interface
Figure 154. The System / Traceroute page. The additional settings window.
In the opened window, you can specify the following parameters:
Parameter Description
Maximum TTL value
Specify the TTL (Time to live) parameter value. The default value is
30.
Number of probes The number of attempts to hit an intermediate host.
Wait time
A period of waiting for an intermediate host response.
To restore the default field values, click the DEFAULT SETTINGS button.
After specifying the additional parameters, click the OK button.
To run the check, click the START button. After a while, the results will be displayed on the page.
To remove the check result from the page, click the CLEAR button.
