D-Link DSL-2877AL User Manual

D-Link DSL-2877AL Dual Band Wireless AC750 VDSL/ADSL2+ Modem Router User Manual
Section 3 - Web User Interface Configuration
Page 45
WEP-64Bits/WEP-128Bits for 2.4Ghz and 5Ghz Wireless Configuration
Make sure that all wireless devices on your network are using the same encryption
level and key. WEP keys must consist of the letters "A" through "F" and the numbers
"0" through "9".
WPA Type for 2.4Ghz and 5Ghz Wireless Configuration
This router supports two type options available in the WPA Type.
The types are the 802.1x and PSK Value.
802.1x
WPA RADIUS uses an external RADIUS server to perform user authentication. To
use WPA RADIUS, enter the IP address of the RADIUS server, the RADIUS Port
(default is 1812) and the shared secret from the RADIUS server.

D-Link DSL-2877AL Specifications

General

LAN Ports	4 x 10/100Mbps
USB Ports	1 x USB 2.0
Frequency Band	2.4 GHz
WAN Ports	1 x RJ-11 DSL port
Antenna Type	2 External Antennas
Security	WPA, WPA2
Weight	270 grams
