D-Link DWA-140 User Manual

10D-Link DWA-140 User Manual
Section 2 - Installation
Warning: Do NOT install the DWA-140 USB Adapter into your computer before installing the driver software
from the D-Link CD.
Turn on the computer and Insert the D-Link DWA-140 Driver CD in the CD-ROM drive. The step-by-step instructions
that follow are shown in Windows XP. The steps and screens are similar for the other Windows operating systems.
If the CD Autorun function does not automatically start on your computer, go to Start > Run. In the run box type
“D:\DWA-140.exe” (where D: represents the drive letter of your CD-ROM drive).
When the autorun screen appears, click Install Drivers.
Adapter Installation
Click Install Drivers

D-Link DWA-140 Specifications

System Requirements

operating system	Windows XP SP2, 2000 SP4, or Vista
hard disk space	20MB
usb port	Available USB port

Standards and Frequency

wireless standards	IEEE 802.11n (draft), IEEE 802.11g, IEEE 802.11b
usb standard	USB 2.0
frequency range	2.4GHz to 2.4835GHz

Data and Power

data rates 802.11g	6/9/12/18/24/36/48/54Mbps
data rates 802.11b	1/2/5.5/11Mbps
data rates 802.11n	30/60/90/120/180/240/270/300Mbps
transmit output power 802.11b	18dbm
transmit output power 802.11g/n	14dbm
operating voltage	5VDC +/- 10%
power consumption TX 802.11n	247mA
power consumption RX 802.11n	268mA

Environmental Specifications

operating temperature	0º to 40º C
storage temperature	-20º to 65º C
operating humidity	10% to 90% non-condensing
storage humidity	5% to 95% non-condensing

Physical Characteristics

antennas	Two integrated antennas
dimensions	87 x 28 x 12 mm
diagnostic LEDs	Link/Activity
