D-Link DWA-140 User Manual

25D-Link DWA-140 User Manual
Section 3 - Configuration
Windows
®
XP Configuration Utility
Windows
®
XP users may use the built-in wireless utility. The following instructions are for Service Pack 2 users.
If you are using Windows
®
2000, you must use the D-Link utility. Please refer to page 15.
Right-click on the wireless computer icon in your system tray
(lower-right corner next to the time). Select View Available
Wireless Networks.
If you receive the Wireless Networks Detected bubble, click
on the center of the bubble to access the utility.
The utility will display any available wireless networks in your
area. Click on a network and click the Connect button.
Refer to the Wireless Security section for information on
connecting to a secure network.
If you want to use the D-Link utility instead of the Windows
®
XP
wireless utility, refer to the next page.

D-Link DWA-140 Specifications

System Requirements

operating system	Windows XP SP2, 2000 SP4, or Vista
hard disk space	20MB
usb port	Available USB port

Standards and Frequency

wireless standards	IEEE 802.11n (draft), IEEE 802.11g, IEEE 802.11b
usb standard	USB 2.0
frequency range	2.4GHz to 2.4835GHz

Data and Power

data rates 802.11g	6/9/12/18/24/36/48/54Mbps
data rates 802.11b	1/2/5.5/11Mbps
data rates 802.11n	30/60/90/120/180/240/270/300Mbps
transmit output power 802.11b	18dbm
transmit output power 802.11g/n	14dbm
operating voltage	5VDC +/- 10%
power consumption TX 802.11n	247mA
power consumption RX 802.11n	268mA

Environmental Specifications

operating temperature	0º to 40º C
storage temperature	-20º to 65º C
operating humidity	10% to 90% non-condensing
storage humidity	5% to 95% non-condensing

Physical Characteristics

antennas	Two integrated antennas
dimensions	87 x 28 x 12 mm
diagnostic LEDs	Link/Activity
