D-Link DWA-192 Quick Install Guide

7
You can now connect to your wireless network by using one of the two
methods shown below:
When your adapter has successfully connected to a wireless network, the
LED will turn solid blue.
A. Open your wireless utility and select the network you want to connect
to. If the network is secure you will be prompted to enter the Wi-Fi
password.
B. If your wireless router or access point supports WPS, press the WPS
button on the back of the adapter and then initiate WPS on your wireless
router or access point within two minutes.
WPS Button
7

D-Link DWA-192 Specifications

Operating Environment

operating temperature	0 °C to 40 °C
operating humidity	10% to 90% maximum (non-condensing)
frequency range	2.4 GHz to 2.4835 GHz, 5.150 GHz to 5.850 GHz

Power

operating voltage	5 V DC +/- 10%
current consumption	880 mA

Weight and Dimensions

weight	167 grams
dimensions	79.92 x 79.92 x 77 mm
