D-Link DWA-192 User Manual

10D-Link DWA-192 User Manual
Section 2 - Installation
The drivers and software will now install. Please allow 1-2 minutes for this
process to nish.
The driver installation process is complete. Click Finish to exit setup.
The DWA-192’s Status LED should be blinking blue (see Hardware
Overview on page 4).
To connect to your wireless network, see Connecting to a Wireless
Network on page 12. Once a connection is established, the Status LED
should be solid blue.

D-Link DWA-192 Specifications

Operating Environment

operating temperature	0 °C to 40 °C
operating humidity	10% to 90% maximum (non-condensing)
frequency range	2.4 GHz to 2.4835 GHz, 5.150 GHz to 5.850 GHz

Power

operating voltage	5 V DC +/- 10%
current consumption	880 mA

Weight and Dimensions

weight	167 grams
dimensions	79.92 x 79.92 x 77 mm
