User Manual of DWR-M961
-15-
Interface Description
WPS Press it will enable WPS functiont
Reset
Press the Reset button gently for 3 seconds and then release it. The system
restores to the factory default settings
WAN
Connect to the Cable/xDSL Modem or the Ethernet
LAN1-4
Connect to the user’s PC or network devices
Power Connect to the power adapter provided in the package
Table 2-2 Interface Indications
2.1.4
Bottom panel
The SIM Card slot of the DWR-M961 at the bottom shows the user how to install the LTE sim card. Figure 2-1-
4-1 shows the sim card slot of the DWR-M961.
Figure 2-1-4-1 sim card slot of the DWR-M961
