User Manual of DWR-M961
-62-
5.3.2.3. IP Filtering
Figure 5-3-4 IP Filtering
Object Description
Enable IP Filtering
Enable or disable IP Filtering function.
Enable IPv4
Enable or disable IPv4 Filtering feature.
Enable IPv6
Enable or disable IPv6 Filtering feature.
Local IPv4 Address
Set LAN side source IPv4 address
Local IPv6 Address
Set LAN side source IPv6 address
Protocol
Select “TCP”, “UDP” or” Both”
Comment
Comment for the rule.
