DES-3526 / DES-3526DC Layer 2 Fast Ethernet Switch CLI Reference Manual
106
config link_aggregation algorithm
Purpose Used to configure the link aggregation algorithm.
Syntax
config link_aggregation algorithm [mac_source | mac_destination |
mac_source_dest | ip_source | ip_destination | ip_source_dest]
Description This command configures the part of the packet examined by the Switch
when selecting the egress port for transmitting load-sharing data. This
feature is only available using the address-based load-sharing algorithm.
Parameters
mac_source − Indicates that the Switch should examine the MAC source
address.
mac_destination − Indicates that the Switch should examine the MAC
destination address.
mac_source_dest − Indicates that the Switch should examine the MAC
source and destination addresses
ip_source − Indicates that the Switch should examine the IP source
address.
ip_destination − Indicates that the Switch should examine the IP
destination address.
ip_source_dest − Indicates that the Switch should examine the IP source
address and the destination address.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure link aggregation algorithm for mac-source-dest:
DES-3526:4#config link_aggregation algorithm mac_source_dest
Command: config link_aggregation algorithm mac_source_dest
Success.
DES-3526:4#
show link_aggregation
Purpose Used to display the current link aggregation configuration on the
Switch.
Syntax
show link_aggregation {group_id <value 1-6> | algorithm}
Description This command will display the current link aggregation configuration
of the Switch.
Parameters
<value 1-6> − Specifies the group ID. The Switch allows up to 6 link
aggregation groups to be configured. The group number identifies
each of the groups.
algorithm − Allows you to specify the display of link aggregation by
the algorithm in use by that group.
Restrictions None.
Example usage:
To display Link Aggregation configuration:
