Commissioning, inter lock function
Communication C95
In order to have communication between two EP102 panels, C95 should be set to the appropriate
values..
On the first panel C95 is set to 1 and on the second C95 is set to 2.
The first panel starts sending values to the second panel, which answers by returning values. When
C95=0 communication is off. As soon as another value than 0 is set communication starts.
If the communication does not work an error message is shown.
E14=Error in communication, second panel does not answer.
The error message is shown as long as the communication is broken and will continue to show until
both panels are correctly set. Error message will also be shown if one of the EP 102 panels is without
power.
Heat Lock, C64=1
Only one door can be opened at a time, C64=1 is set on both EP 102 panels. Opening is possible only
when the other door is closed. Both doors can shut independently of each other.
Eg:: To work automatically set C62=3. By sending a signal to the panel the first doors opens, closes
and opens then the other door.
If the stop circuit is broken for more than 5 sec. the door is regarded as disabled and the other door
can be opened independently. (Breaking the interlock during the summer).
Description: The first door is opened. When in the fully open position the stop button with lock is
pressed. The second door can then be independently operated, although the first door is open.
To reset the heat lock function make sure that the second door is in closed position before releasing
the stop button.
Blocking of open C64=2
Can only be opened when the other door is open. The other door is than set to C64=3.
To set both EP 102 to C64=2 is not allowed since when both are closed it is not possible to open.
Eg: (C62=3 is set.) A barrier is set to C64=2 and a gate is set to C62=3. When sending a signal to
prog. input 1 on the barrier the gate will open and when it is open it will send a signal back to the
barrier which will open. If automatic closing is activated the barrier closes first and when it is closed it
closes the gate.
Blocking of close C64=3
Can only close if the other door is closed. To set both EP 102 to C64=3 is not allowed since when both
doors are open it is not possible to close.
Ex: (C62=3 is set). A gate is set to C64=3 and a barrier is set to C64=2. When sending a signal to
Prog. input 1 the gate will open and when it is open it will send a signal to the barrier which opens. If
automatic closing is activated the barrier closes first and then the gate.
