Channel list for EP102
The channel list is the same for control type EP102-1 (1 motor) and control type EP102-2 (2 motors).
Certain channels apply only to control type EP102-2. These are marked by an * before the channel
number.
Measured value to be read
No. Specification Range
C00 Service channel, only for service personnel 000-999
C01 Program version 0.00-9.99
C02 Mains voltage, phase L1.(Accuracy of measurement +- 15%) 000-255 V
C03 Voltage after stop circuit 00.0-30.0 V
C04 Resistance, safety buffer close 1 (KSS1)
0.0-3.00 kΩ
C05 Resistance, safety buffer close 2 (KSS2)
0.0-3.00 kΩ
C06 Resistance, safety buffer open (KSÖ)
0.0-3.00 kΩ
C07 Load, motor 1
0.00-0.99 Cos ϕ
*C08 Load, motor 2
0.00-0.99 Cos ϕ
C09 Motor current, motor 1 0.0-5.0 A
*C10 Motor current, motor 2 0.0-5.0 A
C11 Running time. motor 1 00-99 Sec
*C12 Running time, motor 2 00-99 Sec
C13 Time motor 1 opened from closed position
Used for limited opening
00.0-59.9 Sec
C14 Number of openings (Total no of openings =C14+C15) 000-999 times
C15 Number of openings x1000 000-999 times
Commissioning: values to be entered when commissioning
No. Specification Value
Range Start Set
C30 Limit for load sensor, motor 1
0.05-0.90 Cos ϕ
0.40
*C31 Limit for load sensor, motor 2
0.05-0.90 Cos ϕ
0.40
C32 Limited running time 05-99 Sec 10
C33 Latched / deadman control
0=Open and close, deadman control
1=Open latched, close deadman control
2=Open deadman control, close latched
3=Open and close, latched
0-3 0
C34 Type of voltage feed. Used for the load sensor.
0=3x400V+N, 1=3x230V, 2=1x230V
0-2 0
Delay of gate half, magnetic lock
No. Specification Value Start Set
*C38 Time delay in opening motor 2 and closing motor 1.
Used for magnetic lock or overlap of gate half
0.1-5.00 sec 0.1
C39 Time delay in opening before motor 1 starts, used for
magnetic lock so that magnet can get rid of remmanence.
0.00-0.99 sec 0.00
