Number of safety buffers, load sensor function and motor protection
No. Specification Value Start Set
C40 Number of safety buffers connected to KSS1, 0=buffer off 0-2 1
C41 Number of safety buffers connected to KSS2, 0=buffer off. 0-2 1
C42 Number of safety buffers connected to KSÖ, 0=buffer off. 0-4 0
C43 Load sensor may be changed only for service and fault-finding.
0=Off 1=KSS 2=KSÖ 3=KSS+KSÖ 4=Stop.
0-4 3
C44 Limit for motor protector, motor 1 0.5-4.0 A 1.5
*C45 Limit for motor protector, motor 2 0.5-4.0 A 1.5
C46 Deadman closure when KSS or FS/SL out of order or actuated.
0=off, cannot be closed 1=can be closed.
0-1 1
C47 Function of safety buffer
0=KSS stop. KSÖ stop.
1=KSS reverse. KSÖ stop.
2=KSS stop. KSÖ reverse.
3=KSS reverse. KSÖ reverse.
0-3 3
Automatic closure and FC/SL closure
No. Specification Value Start Set
C50 Time for automatic closure 0.00-9.59 min.sec 0.00
C51 Max. open time in closure with FC/SL.
Set time = closure with FC/SL 0 = no closure with FC/SL.
0.00-9.59 min.sec 0.00
C52 Time for blocking of automatic closure, after actuation of
stop key.
0.20-9.59 min.sec 5.00
C53 0=No automatic closure after actuation of stop.
1=automatic closure after actuation of stop.
0-1 0
C54 Closure with FC/SL. 0=close as soon as FC/SL is not
actuated. 1=first open fully, then close.
0=immediately
1=fully open
1
Limited opening, opening of a gate half and lock opening
No. Specification Value Start Set
C60 Time for part opening. 0=full opening 00.0-99.9 sec 05.0
C61 Programmable input 2. 0=open only M1
1=open M1+M2
0-1 1
C62 Programmable input 2
0=Turned off
1=Open/stop/close
2=Open only gate half 2
3=Interlock.
4=For future use
5=Automatic closing turned off
6=Open gate+automatic closing turned off
0-6 1
C63 Prioritised direction change.
0=none 1=open 2=close 3=open and close
0-4 1
C64 Blocking of another door
0=no blocking
1=blocking of open until the other door is closed.
2=blocking of open until the other door is opened.
3=blocking of close until the other door is closed.
0-3 1
