4
Technical specification
Dimensions (WxHxD) 190x224x60 mm
Weight Model type Ep102-2 =1.7 kg. Model type EP102-1=1.4 kg.
Supply voltage EP102 is suitable for three-phase or single-phase operation.
Supply voltage, three phase 3x400VAC, 3x230VAC, (±10%) Fuse max T10A.
Supply voltage, single phase 1x230VAC (±10%) Fuse max T10A.
Frequency 50Hz
Motor EP102-1 for single drive motor, EP102-2 for two drive motors.
Motor, three-phase operation three-phase induction motor, 0.18-0.55kW.
Motor, single-phase operation single-phase motor with operating condenser 0.18-0.25kW.
Fuses Internal fuse =T4A, external fuse required = T10A.
Power consumption Automatic controls max 22 VA + electric motors.
Temperature range 0 to 50°C
Safety Buffers There are 3 analogue inputs for safety buffer monitoring.
Closing direction 2 inputs, KSS1 and KSS2, for safety buffers - close.
No. of close buffer/inputs 2 safety buffers may be connected to each KSS input terminal.
Opening direction There is one KSÖ input for safety buffers - open.
No. of open buffer/inputs 4 safety buffers may be connected to the KSÖ input terminals.
Resistance 2k with 1% tolerance and power resistance at least ½W.
Safety circuit
Safety and test output 24V/max 0.5A for contactor operation, auto-test of inputs for safety
buffers and limit position.
Stop circuit Max current 300mA when contactors are closed. Voltage drop max
1.0V.
Max resistance Max 3 in stop circuit.
Cable length Cable length: 0.75mm
2
=max 60m. 1.5mm
2
=max 120m.
Inputs 1 analogue input 0-50V meters voltage after stop circuit.
Limit position Current per limit position max 125mA. Voltage drop max 0.5V.
Max resistance 4 in circuit for limit position.
Cable length Cable length: 0.75mm
2
=max 90m. 1.5mm
2
=max 180m.
Inputs See digital inputs.
Motor protection Internal motor protection circuit meters current on phase L1.
Range of measurement 0.5-4 A
Load sensor Measures phase shift between voltage and current.
Range of measurement cos φ = 0.05-0.90
Digital inputs (9) For operation and control of gate.
Logic 0 0-8V
Logic 1 12-30V
Input current 5mA at 24V
Supply to photocell 24V max 50mA
24V DC output 24V DC for supply to external access control or signal devices etc.
Load Max 300mA
Communication RS-485
