DAAB EP102 - Supplementary Card and Time Delays; Supplementary Card Configuration; Time Delay and Communication Settings

23
Displays for supplementary card DB307
No. Specification Value Start Set
C70 Supplementary card 0=none 1=DB307
0=channel 71-82 not shown
1=channel 71-82 shown and can be set
0-1 0
Time delays
No. Description Value Start Set
C90 Time for blocking of load sensor at start 0.01-0.99 sec 0.60
C91 Time for motor protector 0.01-0.99 sec 0.30
C92 Time delay, normal reversing, Open and FC 0.6-1.0 sec 0.8
C93 Time delay, rapid reversing, Safety buffer and load sensor 0.3-1.0 sec 0.4
C94 Time for reversing with KSÖ 1.0-5.0 sec 2.0
Communication, special
No. Specification Value Start Set
C95 Network number for communication. 0=off 0-16 0
C99 Service channel for service personnel only. 0-99 0
