DAAB EP102 - List of Input Signals; Safety and Control Inputs; Photocell, Communication, and Output

7
List of Input Signals
Safety buffer
Name Term. Function
KSS1 1,2 Closing safety buffer, stops gate when closing. Resistance measurement.
KSS2 3,4 Closing safety buffer, stops gate when closing. Resistance measurement.
KSÖ 5,6 Opening safety buffer, stops gate when opening. Resistance measurement.
Stop, safety circuit
Name Term. Function
Safety Out 7 Output for safety circuit 24V/0.5A
Stop 7,8 Stops gate. Contact normally closed, wire link required if not used.
Stop 9,10 Stops gate. Contact normally closed, wire link required if not used.
Stop 11,12 Stops gate. Contact normally closed, wire link required if not used.
Limit positions, safety circuit
Name Term. Function
TB1 13 Motor 1 thermoswitch, cuts out at high temperature.
GÖ1 14 Opening limit switch for motor 1. Breaks contact in fully open position.
GS1 15 Closing limit switch for motor 1. Breaks contact in fully closed position.
TB2 16 Motor 2 thermoswitch, cuts out at high motor temperature.
GÖ2 17 Opening limit switch for motor 2. Breaks contact in fully open position.
GS2 18 Closing limit switch for motor 2. Breaks contact in fully closed position.
Control keys
Name Term. Function
+24VDC 19 24V DC output for access controls.
Open 20 Open gate on open signal 24V DC.
Close 21 Close gate on close signal 24V DC .
+24V DC 22 24V DC output for access controls.
Open 23 Open gate on open signal 24V DC.
Close 24 Close gate on close signal 24V DC.
+24V DC 25 24V DC output for access controls.
Open/stop/
close
Prog. Input 1
26 Open/Stop/Close by pulse from single remote push button for gate leaf 1. OR
Interlock / siphon, OR automatic closing disconnected.
Part opening
Prog Input 2
27 Full or partial opening of gate leaf 1
Photocell, safety loop
Name Term. Function
+24V DC 28 Output for photocell/Induction loop 24V/50mA.
FC/SL 29 Photocell/loop, stops gate when closing. Contact normally closed, when powered.
0V 30 Earth connection.
Communication
Name Term. Function
RS485 31,32 Communication with a separate DAAB panel.
24V DC output
Name Term. Function
+24V DC 33 24V DC for supply to additional access controls
0V 34 Earth termination.
