⑬ OUT1, 2 : Analog (DC 0 ~10V/DC 4 ~ 20mA) Output Terminal
⑭ GND : External Input Common Terminal
⑮ IN1 : External HOLD Input Terminal (CH1)
⑯ IN2 : External ZERO Input Terminal (CH1)
○
17
IN3 : External HOLD Input Terminal (CH2)
○
18
IN4 : External ZERO Input Terminal (CH2)
○
19
COM : RELAY Output Common Terminal
○
20
RY1 : CH1 Lower Limit Output Terminal
○
21
RY2 : CH1 Upper Limit Output Terminal
○
22
RY3 : CH2 Lower Limit Output Terminal
○
23
RY4 : CH2 Upper Limit Output Terminal
◀Attention▶
1. When wiring, please pull out the power plug. (Main power supply)
2. Please use the thick calbe for ground terminal ( ) so that you can avoid any trouble
due to the impulse voltage or surge. If possible, please keep it as an independent
ground.
(This must be used in the area with heavy noise. If the ground is made with other
device, it will be affected by noise.)
3. Please check the function of the terminal before you do the wiring so that you can
prevent any malfunction in advance.
4. Manufacture will be relieved of its responsibility for any damge or injury due to the
disassembly and alteration made without any agreement. Also, no A/S will be made.
