Page 8-4
DACOR RANGE SERVICE MANUAL
Pull the island trim/backguard J up and off
the range.
Remove the stainless steel spill tray trim piece
L .
•
•
Remove the electrical access panel cover N
by removing the two (2) screws M that hold
it in place.
Remove the two (2) screws
O on the
sides of the electrical access panel. It is not
necessary to remove the gas regulator access
panel cover
P .
•
•
Remove all of the remaining screws from the
back panel and pull it off.
•
J
L
M
M
N
O
O
P
Removing the Back Panel (continued)
To Next Page
