Page 8-5
SECTION 8 - RANGE DISASSEMBLY
Remove the end cap.•
Removing the Side Panel(s)
Loosen the end cap set screws B through
the access holes
C on the bottom of the
front panel lip
D .
•
D
B
C
Turn off the gas supply at the supply valve
and power to the range at the junction or fuse
box.
Pull the range out from the wall or cabinet
Remove all of the screws from the edge of the
back panel
A on the same side of the range
as the side panel being removed.
•
•
•
A
