Page 9-7
SECTION 9 - COMPONENT REPAIR
Inner Window Assembly (continued)
Remove the four (4) screws J that hold the
outer heat shield
K in place. Lift the outer
heat shield out.
•
Remove the four (4) screws L that hold the
lower outer heat shield
M in place. Lift the
lower heat shield out.
•
Remove the four (4) screws N that hold the
inner heat shield
O in place. Lift the inner
heat shield up and out toward the top of the
door.
•
Push the glass window assembly out of the
door liner from the bottom and lift it out.
•
J
K
J
J
J
L
L
L
L
M
N
N
N
N
O
