Page 9-33
SECTION 9 - COMPONENT REPAIR
E
F
Control Panel Repair (continued)
Remove the screws from the bottom of the
cooktop front panel
D .
•
Make sure the oven control panel E is in the
lowered position. See page 5-2.
Pull the bottom of the front panel
F out and
lift it up and off the range.
•
•
Remove all of the screws that hold the
channel support
G to the cooktop chassis.
Lift the channel support out of the chassis.
•
D
G
To Next Page
