0
2
4
6
8
10
12
14
16
0 10 20 30 40 50 60 70
Performance Curve QB1 V1.5DC Pump
QB1 V1.5DC 1pompa*
22 | QB1 User Manual
QB1 V1.5DC
Pump Single head diaphragm 24Vdc
Nominal max owrate 16 l/min
Flowmeters scale indication 0.2 ÷ 3.0 2 ÷ 30 Nl/min
Overall weight 9 Kg without battery
Power supply 230Vac ± 10% 50/60Hz - 50 W Fuse 1.6A
Ingresso 24 Vdc With external connector, power consumption 2.5 Ah
