Dado Lab QB1 - QB1 V2 X5 Dc; Qb1 -D

0
1
2
3
4
5
6
0 10 20 30 40 50 60 70 80 90 100
Performance Curve QB1 Pumps
QB1 V2x5DC
ENGLISH | 23
QB1 -D
Pump x2 Single head diaphragm 24Vdc
Nominal max owrate 5 l/min
Flowmeters scale indication 0.1 ÷ 2.0 0.1 ÷ 2.0 Nl/min
Overall weight 13 Kg including batteries
Power supply 230Vac ± 10% 50/60Hz Fuse 1.6A
Built-in batteries x2 12Vdc 2.3 Ah
QB1 V2x5DC
Pump x2 Single head diaphragm 24Vdc
Nominal max owrate 11 l/min
Flowmeters scale indication 0.2 ÷ 5.0 0.2 ÷ 5.0 Nl/min
Overall weight 13 Kg including batteries
Power supply 230Vac ± 10% 50/60Hz Fuse 1.6A
Built-in batteries x2 12Vdc 2.3 Ah
