EXPLODE VIEW AND PARTS LIST
■ Detailed Part Code of PCB AS
PRPSSWB200 DWD-FU104, PANA MICOM, EC, 1000RPM, HOT V/V, BB
PRPSSWB201 DWD-FU104, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB
PRPSSWB202 DWD-FU104, PANA MICOM, EC, 1000RPM, COLD V/V, BB
PRPSSWB203 DWD-FU104, PANA MICOM, EC, 1000RPM, COLD V/V, NON-BB
PRPSSWB204 DWD-FU124, PANA MICOM, EC, 1200RPM, HOT V/V, BB
PRPSSWB205 DWD-FU124, PANA MICOM, EC, 1200RPM, HOT V/V, NON-BB
PRPSSWB206 DWD-FU124, PANA MICOM, EC, 1200RPM, COLD V/V, BB
PRPSSWB207 DWD-FU124, PANA MICOM, EC, 1200RPM, COLD V/V, NON-BB
PRPSSWB208 DWD-FU104, PANA MICOM, NON-EC, 1000RPM, HOT V/V, BB
PRPSSWB209
DWD-FU104, PANA MICOM, NON-EC, 1000RPM, HOT V/V, NON-BB
PRPSSWB210 DWD-FU104, PANA MICOM, NON-EC, 1000RPM, COLD V/V, BB
PRPSSWB211
DWD-FU104, PANA MICOM, NON-EC, 1000RPM, COLD V/V, NON-BB
PRPSSWB212 DWD-FU124, PANA MICOM, NON-EC, 1200RPM, HOT V/V, BB
PRPSSWB213
DWD-FU124, PANA MICOM, NON-EC, 1200RPM, HOT V/V, NON-BB
PRPSSWB214 DWD-FU124, PANA MICOM, NON-EC, 1200RPM, COLD V/V, BB
PRPSSWB215
DWD-FU124, PANA MICOM, NON-EC, 1200RPM, COLD V/V, NON-BB
PRPSSWB460 DWD-FU104, PANA, EC,1000RPM, HOT VV, BB, VDE+1W
PRPSSWB461 DWD-FU104, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W
PRPSSWB462 DWD-FU104, PANA, EC,1000RPM, COLD VV, BB, VDE+1W
PRPSSWB463 DWD-FU104, PANA, EC,1000RPM, COLD VV, NON-BB, VDE+1W
PRPSSWB464 DWD-FU124, PANA, EC,1200RPM, HOT VV, BB, VDE+1W
PRPSSWB465 DWD-FU124, PANA, EC,1200RPM, HOT VV, NON-BB, VDE+1W
PRPSSWB466 DWD-FU124, PANA, EC,1200RPM, COLD VV, BB, VDE+1W
PRPSSWB467 DWD-FU124, PANA, EC,1200RPM, COLD VV, NON-BB, VDE+1W
PRPSSWB468 DWD-FU104,PANA,NON-EC,1000RPM,HOT VV,BB, VDE+1W
PRPSSWB469
DWD-FU104,PANA,NON-EC,1000RPM,HOT VV,NON-BB, VDE+1W
PRPSSWB470 DWD-FU104,PANA,NON-EC,1000RPM,COLD VV,BB, VDE+1W
PRPSSWB471
DWD-FU104,PANA,NON-EC,1000RPM,COLD VV,NON-BB, VDE+1W
PRPSSWB472 DWD-FU124,PANA,NON-EC,1200RPM,HOT VV,BB, VDE+1W
PRPSSWB473
DWD-FU124,PANA,NON-EC,1200RPM,HOT VV,NON-BB, VDE+1W
PRPSSWB474 DWD-FU124,PANA,NON-EC,1200RPM,COLD VV,BB, VDE+1W
PRPSSWB475
DWD-FU124,PANA,NON-EC,1200RPM,COLD VV,NON-BB, VDE+1W
PRPSSWB480 DWD-FU105, PANA, EC,1000RPM, HOT VV, BB, VDE+1W
PRPSSWB481 DWD-FU105, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W
PRPSSWB482 DWD-FU105, PANA, EC,1000RPM, COLD VV, BB, VDE+1W
PRPSSWB483 DWD-FU105, PANA, EC,1000RPM, COLD VV, NON-BB, VDE+1W
PRPSSWB484 DWD-FU125, PANA, EC,1200RPM, HOT VV, BB, VDE+1W
PRPSSWB485 DWD-FU125, PANA, EC,1200RPM, HOT VV, NON-BB, VDE+1W
PRPSSWB486 DWD-FU125, PANA, EC,1200RPM, COLD VV, BB, VDE+1W
PRPSSWB487 DWD-FU125, PANA, EC,1200RPM, COLD VV, NON-BB, VDE+1W
PRPSSWB488 DWD-FU105,PANA,NON-EC,1000RPM,HOT VV,BB, VDE+1W
PRPSSWB489
DWD-FU105,PANA,NON-EC,1000RPM,HOT VV,NON-BB, VDE+1W
PRPSSWB490 DWD-FU105,PANA,NON-EC,1000RPM,COLD VV,BB, VDE+1W
PRPSSWB491
DWD-FU105,PANA,NON-EC,1000RPM,COLD VV,NON-BB, VDE+1W
PRPSSWB492 DWD-FU125,PANA,NON-EC,1200RPM,HOT VV,BB, VDE+1W
PRPSSWB493
DWD-FU125,PANA,NON-EC,1200RPM,HOT VV,NON-BB, VDE+1W
PRPSSWB494 DWD-FU125,PANA,NON-EC,1200RPM,COLD VV,BB, VDE+1W
PRPSSWB495
DWD-FU125,PANA,NON-EC,1200RPM,COLD VV,NON-BB, VDE+1W
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
4th PANEL
DWD-
FT1X4X
SERIES
(NON-1W)
4th PANEL
DWD-
FT1X4X
SERIES
(VDE+1W)
5th PANEL
DWD-
FT1X5X
SERIES
(VDE+1W)
1B06 PCB AS
To Next Page
