EXPLODE VIEW AND PARTS LIST
■ Detailed Part Code of PCB AS
PRPSSWB500
DWD-FU106, PANA, EC,1000RPM, HOT VV, BB, VDE+1W, ISLAMIC RINSE
PRPSSWB501 DWD-FU106, PANA, EC,1000RPM, HOT VV, BB, VDE+1W
PRPSSWB502
DWD-FU106, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB503 DWD-FU106, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W
PRPSSWB504
DWD-FU106, PANA, EC,1000RPM, COLD VV, BB, VDE+1W, ISLAMIC RINSE
PRPSSWB505 DWD-FU106, PANA, EC,1000RPM, COLD VV, BB, VDE+1W
PRPSSWB506
DWD-FU106, PANA, EC,1000RPM, COLD VV, NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB507 DWD-FU106, PANA, EC,1000RPM, COLD VV, NON-BB, VDE+1W
PRPSSWB508
DWD-FU126, PANA, EC,1200RPM, HOT VV, BB, VDE+1W, ISLAMIC RINSE
PRPSSWB509 DWD-FU126, PANA, EC,1200RPM, HOT VV, BB, VDE+1W
PRPSSWB510
DWD-FU126, PANA, EC,1200RPM, HOT VV, NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB511 DWD-FU126, PANA, EC,1200RPM, HOT VV, NON-BB, VDE+1W
PRPSSWB512
DWD-FU126, PANA, EC,1200RPM, COLD VV, BB, VDE+1W, ISLAMIC RINSE
PRPSSWB513 DWD-FU126, PANA, EC,1200RPM, COLD VV, BB, VDE+1W
PRPSSWB514
DWD-FU126, PANA, EC,1200RPM, COLD VV, NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB515 DWD-FU126, PANA, EC,1200RPM, COLD VV, NON-BB, VDE+1W
PRPSSWB516
DWD-FU106,PANA,NON-EC,1000RPM,HOT VV,BB, VDE+1W, ISLAMIC RINSE
PRPSSWB517 DWD-FU106,PANA,NON-EC,1000RPM,HOT VV,BB, VDE+1W
PRPSSWB518
DWD-FU106,PANA,NON-EC,1000RPM,HOT VV,NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB519
DWD-FU106,PANA,NON-EC,1000RPM,HOT VV,NON-BB, VDE+1W
PRPSSWB520
DWD-FU106,PANA,NON-EC,1000RPM,COLD VV,BB, VDE+1W, ISLAMIC RINSE
PRPSSWB521 DWD-FU106,PANA,NON-EC,1000RPM,COLD VV,BB, VDE+1W
PRPSSWB522
DWD-FU106,PANA,NON-EC,1000RPM,COLD VV,NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB523
DWD-FU106,PANA,NON-EC,1000RPM,COLD VV,NON-BB, VDE+1W
PRPSSWB524
DWD-FU126,PANA,NON-EC,1200RPM,HOT VV,BB, VDE+1W, ISLAMIC RINSE
PRPSSWB525 DWD-FU126,PANA,NON-EC,1200RPM,HOT VV,BB, VDE+1W
PRPSSWB526
DWD-FU126,PANA,NON-EC,1200RPM,HOT VV,NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB527
DWD-FU126,PANA,NON-EC,1200RPM,HOT VV,NON-BB, VDE+1W
PRPSSWB528
DWD-FU126,PANA,NON-EC,1200RPM,COLD VV,BB, VDE+1W, ISLAMIC RINSE
PRPSSWB529 DWD-FU126,PANA,NON-EC,1200RPM,COLD VV,BB, VDE+1W
PRPSSWB530
DWD-FU126,PANA,NON-EC,1200RPM,COLD VV,NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB531
DWD-FU126,PANA,NON-EC,1200RPM,COLD VV,NON-BB, VDE+1W
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
6th PANEL
DWD-
FT1X6X
SERIES
(VDE+1W)
1B06 PCB AS
NOTE : PCB AS OPTIONS
1. EC(Electricity failure Compensation) Option : EC(Apply EC option), NON-EC(Do not apply EC option).
2. RPM Option : 1000RPM(Apply 101X~107X 1000rpm models), 1200RPM(Apply 121X~127X 1200rpm models).
3. Water Inlet Valve Option : HOT VV(Apply cold Inlet valve and hot inlet valve), COLD VV(Apply cold inlet valve only).
4. Bubble Pump Option : BB(Apply bubble pump), NON-BB(Do not apply bubble pump).
5. 1W Standby Power Option : 1W(Apply 1W standby power option), NON-1W(Do not apply 1W standby power option).
6. Function Button Option : ISLAMIC RINSE(Apply 'Islamic Rinse' function), Others(Apply 'Water+' function).
To Next Page
