EXPLODE VIEW AND PARTS LIST
PRPSSWB532
DWD-FU107, PANA, EC,1000RPM, HOT VV, BB, VDE+1W, ISLAMIC RINSE
PRPSSWB533 DWD-FU107, PANA, EC,1000RPM, HOT VV, BB, VDE+1W
PRPSSWB534
DWD-FU107, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB535 DWD-FU107, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W
PRPSSWB536
DWD-FU107, PANA, EC,1000RPM, COLD VV, BB, VDE+1W, ISLAMIC RINSE
PRPSSWB537 DWD-FU107, PANA, EC,1000RPM, COLD VV, BB, VDE+1W
PRPSSWB538
DWD-FU107, PANA, EC,1000RPM, COLD VV, NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB539 DWD-FU107, PANA, EC,1000RPM, COLD VV, NON-BB, VDE+1W
PRPSSWB540
DWD-FU127, PANA, EC,1200RPM, HOT VV, BB, VDE+1W, ISLAMIC RINSE
PRPSSWB541 DWD-FU127, PANA, EC,1200RPM, HOT VV, BB, VDE+1W
PRPSSWB542
DWD-FU127, PANA, EC,1200RPM, HOT VV, NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB543 DWD-FU127, PANA, EC,1200RPM, HOT VV, NON-BB, VDE+1W
PRPSSWB544
DWD-FU127, PANA, EC,1200RPM, COLD VV, BB, VDE+1W, ISLAMIC RINSE
PRPSSWB545 DWD-FU127, PANA, EC,1200RPM, COLD VV, BB, VDE+1W
PRPSSWB546
DWD-FU127, PANA, EC,1200RPM, COLD VV, NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB547 DWD-FU127, PANA, EC,1200RPM, COLD VV, NON-BB, VDE+1W
PRPSSWB548
DWD-FU107,PANA,NON-EC,1000RPM,HOT VV,BB, VDE+1W, ISLAMIC RINSE
PRPSSWB549 DWD-FU107,PANA,NON-EC,1000RPM,HOT VV,BB, VDE+1W
PRPSSWB550
DWD-FU107,PANA,NON-EC,1000RPM,HOT VV,NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB551
DWD-FU107,PANA,NON-EC,1000RPM,HOT VV,NON-BB, VDE+1W
PRPSSWB552
DWD-FU107,PANA,NON-EC,1000RPM,COLD VV,BB, VDE+1W, ISLAMIC RINSE
PRPSSWB553 DWD-FU107,PANA,NON-EC,1000RPM,COLD VV,BB, VDE+1W
PRPSSWB554
DWD-FU107,PANA,NON-EC,1000RPM,COLD VV,NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB555
DWD-FU107,PANA,NON-EC,1000RPM,COLD VV,NON-BB, VDE+1W
PRPSSWB556
DWD-FU127,PANA,NON-EC,1200RPM,HOT VV,BB, VDE+1W, ISLAMIC RINSE
PRPSSWB557 DWD-FU127,PANA,NON-EC,1200RPM,HOT VV,BB, VDE+1W
PRPSSWB558
DWD-FU127,PANA,NON-EC,1200RPM,HOT VV,NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB559
DWD-FU127,PANA,NON-EC,1200RPM,HOT VV,NON-BB, VDE+1W
PRPSSWB560
DWD-FU127,PANA,NON-EC,1200RPM,COLD VV,BB, VDE+1W, ISLAMIC RINSE
PRPSSWB561 DWD-FU127,PANA,NON-EC,1200RPM,COLD VV,BB, VDE+1W
PRPSSWB562
DWD-FU127,PANA,NON-EC,1200RPM,COLD VV,NON-BB, VDE+1W, ISLAMIC RINSE
PRPSSWB563
DWD-FU127,PANA,NON-EC,1200RPM,COLD VV,NON-BB, VDE+1W
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
7th PANEL
DWD-
FT1X7X
SERIES
(VDE+1W)
1B06 PCB AS
NOTE : PCB AS OPTIONS
1. EC(Electricity failure Compensation) Option : EC(Apply EC option), NON-EC(Do not apply EC option).
2. RPM Option : 1000RPM(Apply 101X~107X 1000rpm models), 1200RPM(Apply 121X~127X 1200rpm models).
3. Water Inlet Valve Option : HOT VV(Apply cold Inlet valve and hot inlet valve), COLD VV(Apply cold inlet valve only).
4. Bubble Pump Option : BB(Apply bubble pump), NON-BB(Do not apply bubble pump).
5. 1W Standby Power Option : 1W(Apply 1W standby power option), NON-1W(Do not apply 1W standby power option).
6. Function Button Option : ISLAMIC RINSE(Apply 'Islamic Rinse' function), Others(Apply 'Water+' function).
■ Detailed Part Code of PCB AS
