Maintenance and Servicing Procedures
(1) A diagram of the component parts is provided
near the front each section in order to give the
reader a better understanding of the installed
condition of component parts.
(2) The numbers provided within the diagram
indicate the sequence for maintenance and
servicing procedures; the symbol indicates a
non-reusable part; the tightening torque is
provided where applicable.
• Removal steps:
The part designation number corresponds to the
number in the illustration to indicate removal steps.
• Installation steps:
Specified in case installation impossible in reverse
order of removal steps. Omitted if installation is
possible in reverse order of removal steps.
• Disassembly steps:
The part designation number corresponds to the number
in the illustration to indicates disassembly steps.
• Reassembly steps.
Specified in case reassembly is impossible in
reverse order of disassembly steps. Omitted if
reassembly is possible in reverse order of
disassembly steps.
N
G424 Service Manual General Information
GENERAL INFORMATION
How To Read This Manual
Scope of Explanation
This book describes the service procedures for the engine removed from the vehicle.
For procedures concerning removal of the engine from the vehicle and on-vehicle inspection and servicing, refer
to the appropriate service manuals separately prepared for the individual models.
4
Classification of Major Maintenance/Service points
When there are major points relative to maintenance and servicing procedures (such as essential
maintenance and service points, maintenance and service standard values, information regarding the
use of special tools, etc.), these are arranged together as major maintenance and service points and
explained in detail.
A : Indicates that there are essential points for removal or disassembly.
B : Indicates that there are essential points for installation or reassembly.
Symbols for Lubrication, Sealants and
Adhesives
Information concerning the locations for
lubrication and for application of sealants and
adhesives if provided, by using symbols, in the
diagram of component parts, or on the page
following the component parts page, and
explained.
.... Sealant or adhesive
.... Engine oil or gear oil
Inspection
Only the inspections to be performed by using special tools or measuring instruments are covered. General
service procedures not covered in this manual, such as visual inspections and cleaning of parts, however, should
always be performed during actual service operations.
To Next Page
