022-00028AE Operation and Maintenance Manual Inspection, Maintenance and Adjustment 4-33
GREASE DRIVE SHAFTS
1. Grease fitting for center bearing, 1
location. Use remote grease fitting
mounted on frame (3, Figure 61).
AXLE DIFFERENTIAL AND PLANETARIES OIL REPLACEMENT (AFTER FIRST 250 HOURS)
NOTE:
The differential and planetaries oil should be drained and refilled after first 250 hours of
operation. There after every 1,500 hours of operation. (See page 4-43)
REPLACEMENT OF TRANSMISSION OIL AND FILTER (AFTER FIRST 250 HOURS)
NOTE:
Transmission oil and filter must be changed after first 250 hours of operation to comply
with new machine break-in requirements.
NOTE:
After first change, oil and filter should be changed every 1,000 hours. Follow procedure
under 1,000 hour maintenance interval. (See page 4-39)
Reference
Number
Remote Grease
Fittings
1 and 2
50 Hours
Steering Cylinder
Head Ends
3
250 Hours
Drive Shaft
Center Bearing
Figure 61
Figure 62
