2-40 Operating Controls 022-00028AE Operation and Maintenance Manual
5. STORAGE BOX
There is a storage box (1, Figure 72)
behind the seat. Keep the operation
maintenance manual and other documents
in this compartment.
6. WASHER TANK
Contains windshield washer fluid.
7. HOT/COLD REFRIGERATOR
There is a hot/cold refrigerator (1, Figure
74) behind and to the left of the seat. Air
conditioner and heating unit must be
operated after starting the engine for this
function. Keep the cover close for proper
function.
8. ELECTRIC BOX
Under the seat are two pullout trays that
contain relays for unit. (See “Fuse Box/
Relay” on page 2-55.)
1
HBOI431L
Figure 72
HBOM680I
Figure 73
1
HBOI432L
Figure 74
Figure 75
