2-52 Operating Controls 022-00028AE Operation and Maintenance Manual
6. ANGLE ADJUSTMENT OF ARMREST
Adjustment angle of left and right armrest
(6, Figure 97) is done by turning a dial in
bottom of armrest. When you adjust angle,
manually raise armrest before turning dial.
7. HEADREST
Headrest (7, Figure 97) can be adjusted
forward/backward and up/down. Move it by
holding both sides.
HAOB130L
Figure 97
To Next Page
