Dahua Technology DHI-XVR5232AN-S2 - Page 14

User's Manual
6
Remove the case cover along the direction shown in the following arrow.
Remove cover
Match the four holes on the baseboard to place the HDD.
Place HDD
Turn the device upside down, match the screws with the holes on the HDD and then fasten
them. The HDD is fixed to the baseboard.
