User's Manual
16
3.1.5 DHI-XVR7816S-4KL
Front panel
Table 3-5 Front panel description
No.
Port Name
Function
1 IR receiver Receives infrared signal from remote control.
2 USB port
Connects to peripheral devices such as USB storage device,
keyboard, and mouse.
Rear Panel
3.2.1 DHI-XVR5108HS-4KL/DHI-XVR5116HS-S2
Rear panel
Table 3-6 Rear panel description
No.
Port Name
Function
1 Video input port Connects to analog camera to input video signal.
2 Audio input port Receives audio signal output from the devices such as microphone.
3
Audio output
port
Outputs audio signal to the devices such as the sound box.
4 HDMI port
High definition audio and video signal output port.
The port outputs the uncompress
ed high definition video and
multi-channel audio data to the connected display with HDMI port.
5 Network port Connects to Ethernet port.
