User's Manual
73
Table 5-16 Display parameters
Parameter
Description
Main
Screen
Out Port Indicates the main screen port.
Time Title Select the
Time Title
check box, the current system time displays
in each channel window in live view screen. To hide the time,
clear the check box.
Channel Title Select the
Channel Title
check box, the channel name, channel
number and recording status display in each channel window in
live view screen. To hide the time, clear the check box.
Original Rate Select the
Original Rate
check box, the video image displays in
its actual size in the channel window.
IVS Rule
Preview
Select the
IVS Rule Preview
check box to enable IVS rule preview
function.
Transparency Configure the transparency of the graphical user interface (GUI).
The higher the value, the more transparent the GUI becomes.
Resolution Select resolution for the video. The default resolution for VGA
port and HDMI port is 1280×1024.
Some of the resolution options might not be supported on the
HDMI port.
Preview Mode General: No information is displayed on the channel window.
Show Face List: Displays the detected face snapshots taken as
a result of face detection on the bottom of the live view
screen.
Not all models support this function.
Extra
Screen
Enable Enable extra screen function. After this function is enabled, you
can select which port as extra screen port, and the other port
automatically becomes the main screen port.
Out Port Select the VGA port or HDMI port as the port connected by a
secondary monitor. For example, if you select HDMI port as the
extra screen port, the VGA port automatically becomes the main
screen port.
Resolution Select resolution for the video. The default resolution for VGA
port and HDMI port is 1280×720.
Some of the resolution options might not be supported on the
HDMI port.
The main menu does not display on the extra screen.
If you do not enable the extra screen function, both the VGA port and HDMI port display
the same image.
